Brand New Right Front CV Drive Shaft
***Suits AWD, Auto Transmission | Please Check OE Before Fitting***
Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles and speeds without friction, even at high revolutions.
Vehicle Fitment
- Mazda CX-3 DK DK4WS (03/2015~08/2018) 1.5L Diesel S5-DPTS
- Mazda CX-3, CX-3 GSX DK DK4W7 (03/2015~01/2023) 2.0L Petrol PE-VPS
- Mazda CX-3 DK DK4W8 (08/2018~2027) 1.8L Diesel 18D
⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.
Sizing and Specifications
-
Length (Compressed): 984 mm
-
Spline Count - Outer/Wheel Side: 28
-
Spline Count - Inner/Diff Side: 31
-
Inboard Joint Type: Tripod
-
Outboard Joint Type: Ball
-
Bearing Outer Diameter on Extension Shaft: 70 mm
-
Hub Nut: M22 x 1.5
-
Extension Shaft Length From Outside of Bearing: 415 mm
What's Included
All components include a 12 month/20,000km warranty and support from our specialist team.
