Brand New Left and Right Front CV Drive Shaft
***PAIR Kit, Suits Manual Vehicles ONLY***
Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene
dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles
and speeds without friction, even at high revolutions.
Vehicle Fitment
-
Ford Focus (08/2015~01/2019 – M9DD – 1.5L Petrol): LZ – includes i
⚠️ Important Notes for You: We strongly advise using the Australian Number Plate lookup to confirm
fitment.
What's Included
- 1 x CVA1784
- 1 x CVA1783
- 2 x CV Axle Shafts
Sizing and Specifications
-
CVA1784
-
Length (Compressed): 970 mm
-
Spline Count - Outer/Wheel Side: 27
-
Spline Count - Inner/Diff Side: 26
-
CVA1783
-
Length (Compressed): 637 mm
-
Spline Count - Outer/Wheel Side: 27
-
Spline Count - Inner/Diff Side: 26
-
Inboard Joint Type: Tripod
-
Outboard Joint Type: Ball
-
Drive Shaft Seal (Inner) ID: 40 mm
-
Hub Nut: M22 x 1.5
Backed by our 12 month/20,000km warranty and technical support.
