CV Axle Drive Shaft - PAIR Left and Right Hand Side DCT FWD
PAIR Kit, FWD DCT Only
Built tough to OEM specifications using heat-treated chrome steel, maximizing product life. High-quality Neoprene dust boots and stainless steel clamps helps to prevent contamination. Moly grease for working at varying angles and speeds without friction, at high revolutions.
Vehicle Fitment For:
- Volvo S60 P3 2.0L B4204T7 Turbo FWD DCT (10/2011 - 05/2014)
Includes Sub-models T5, T5 Luxury, T5 R-Design, T5 Teknik
- Volvo V60 P3 2.0L B4204T7 Turbo FWD DCT (10/2011 - 05/2014)
Includes Sub-models T5, T5 Luxury, T5 R-Design, T5 Kinetic, T5 Teknik, T5 Teknik Ocean Race
Sizing and Specifications
Left CV Shaft
- Length (Compressed): 590mm
- Spline Count - Outer/Wheel Side: 40T
- Spline Count - Inner/Diff Side: 28T
- Inboard Joint Type: Tripod
- Outboard Joint Type: Ball
- Hub Nut Style: M10 x 1.5
Right CV Shaft
- Length (Compressed): 955mm
- Spline Count - Outer/Wheel Side: 40T
- Spline Count - Inner/Diff Side: 28T
- Inboard Joint Type: Tripod
- Outboard Joint Type: Ball
- Extension Shaft Bearing OD: 75mm
- Extension Shaft Bearing Width: 19mm
- Extension Shaft Length From Outside of Bearing: 430mm
- Oil Seal ID - Inner/Diff Side: 33.8mm
- Extension Shaft Length from Inside of Oil Seal Shoulder: 77mm
- Hub Nut Style: M10 x 1.5
What's Included
Our comprehensive range of constant velocity driveshafts is continuing to lead the way in the driveline aftermarket. The excellent performance and quality has resulted in their growing popularity. The range now boasts over 750 individual part numbers, which covers the vast majority of passenger and 4WD applications on Australian roads today. All our CV driveshafts are covered by a 12 month / 20,000 km warranty. Please note: this excludes CV Boots, which are only warranted for 3 months from date of purchase.
