One Brand New Starter Motor
******
Starter motors that set the standard in automotive excellence. Our products are crafted in accordance with stringent international quality standards (ISO/TS16949), ensuring reliability and superior performance for a wide range of vehicles.
Vehicle Fitment
- Suzuki Grand Vitara JB420, JT, SQ420 TL52V, SQ420 TA52V, SQ420 TB52V (04/1998~07/2008) 2.0L Petrol J20A
- Suzuki Grand Vitara JB627, JT, JA627 TX92V (07/2001~07/2008) 2.7L Petrol H27A
- Suzuki Grand Vitara SQ416 TA03V, SQ416 TA03C (01/1998~2005) 1.6L Petrol G16B
- Suzuki Grand Vitara SQ625 TD62V (04/1998~08/2005) 2.5L Petrol H25AL Diesel M9R780
⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.
Sizing and Specifications
-
Voltage: 12 V
-
KW: 1.2 kW
-
Rotation Direction: CW
-
Pinion Teeth: 8 T
-
Pinion at Rest: 5 mm
-
Pinion Diameter: 28 mm
-
Overall Length: 208 mm
-
Mounting Bolt Centre-Centre: 100 mm
-
Mounting Hole Diameter: M10 x 1.25 mm
-
Flange Diameter: 66 mm
What's Included
All components include a 12 month/20,000km warranty and support from our specialist team.
